Disposable Neutral Electrode/ Electrosurgical Grounding Pad
Disposable Neutral Electrode/ Electrosurgical Grounding Pad
  • Disposable Neutral Electrode/ Electrosurgical Grounding Pad

Disposable Neutral Electrode/ Electrosurgical Grounding Pad





Disposable Neutral Electrode/ Electrosurgical Grounding Pad


The Disposable Neutral Electrode/ Electrosurgical Grounding Pad is a disposable, single use, neutral electrode, which provides a return path for high frequency electrical current to the electrosurgical generator. No electrosurgical effect, e.g., cutting and removal of tissue or coagulation, is intended at this electrode.


Technical Parameters

No.ItemDescripiton
1REF NUMBER
GP202S-AC(REM) (Aduit USE, BIPOLAR)
2Main Materials
GEL, Aluminum Foil, Foam/ Non-woven Fabrics, Liner, PE Insulating Piece
3Dimensions

Gel size: 165*37 mm*2

Foam size: 204*106 mm

4Expiration
24 Months
5Connection
Tab connection or preattached with cable
6Impendance ( 200 KHz)
<50.0 Ohms
7Max Tempreture Rise:
4.0 C° at 700 mA
8Sickness
> 10 N
9Classification
Directive 93/42/EEC (D.L. 46/97). Class IIb device
10Safe Standards
ANSI IEC60601-2-2; AAMI-HF18:2001
11Storage
Tempreture: -5°C -40° C, Relative Humidity: 5% - 90%
